The Mix6 is a complete monitor mixing solution for six performers.
The system includes an AN-16/i line-level input module which accepts
up to 16 line-level inputs. Audio is converted to digital and
transmitted via A-Net®, up to 500ft/150m over Cat-5e. A
dedicated
audio thru is available for each input channel, allowing the AN-16/i
to be seamlessly inserted into an existing audio signal path.
The 16-channel A-16II Personal Mixer allows a performer to create
and save up to 16 custom mixes, and gives each performer control over
channel volume, grouping, pan, stereo spread, along with master volume
and tone. The system also includes an MT-1 for each Personal Mixer to
allow the personal mixer to be mounted on any standard mic stand.
The A-16D Pro A-Net Distributor eliminates the need to daisy chain
Personal Mixers, and simplifies set-up by eliminating the need to
connect a power supply to each mixer. The A-16D Pro accepts one Pro16
A-
Net input signal and provides nine parallel outputs, using rugged
EtherCon connectors and standard Cat-5e cables. The A-16D Pro provides
isolated (floating ground) DC power through the eight A-Net Outs; the
ninth output is an unpowered A-Net Thru connector, designed for
distributing a copy of the A-Net signal to a second A-Net Distributor
or remote location.
As with all Aviom personal mixing systems, this six-mix package
can be expanded as needed to include more Personal Mixers at any time.
