AN-16/i v.2 Input Module

• 16 line-level analog inputs
• A-Net In for creating higher-channel-count systems
• Analog thru for each channel

Aviom16/o-Y1 A-Net Card

• One 16-channel A-Net output
• Allows channels to be routed digitally from the Yamaha^® console interface

Partner Products

Aviom technology integrated directly into select manufacturers' products for seamless connectivity.

D800 A-Net Distributor

• Distributes power and audio to up to 8 personal mixers
• A-Net Bridge input for up to four synchronous Pro16 A-Net streams
• Network Mix Back^™ for seamless connection to wireless in-ears

D800-Dante A-Net Distributor

• All of the features of the D800, plus...
• Direct connectivity to a Dante^™ audio network
• Support for up to 64 Dante network channels

D400 A-Net Distributor

• Distributes power and audio to up to 8 personal mixers
• One A-Net input, one A-Net output
• Stereo Link DIP switches
• A-Net Offset DIP switches

D400-Dante A-Net Distributor

• Direct connectivity to a Dante^™ audio network
• Support for up to 32 Dante network channels
• Stereo Link DIP switches

SB4 System Bridge

• Combines up to four 16-channel Pro16 A-Net streams onto a single cable

A360 Channel Manager

• Allows any network slot to be assigned to any mixer channel

A360 Display

• Provides an overview of all channel mix settings, meters, and more
• Allows channels, presets, and groups to be named

MT-1a Mic Stand Mount

• Allows the A640, A360 or A320 Personal Mixer to be mounted on a mic stand

EB-1 Extension Bracket

• Allows the A640, A360, or A320 to be mounted to a mic stand or music stand shaft
• Requires MT-1a

Replacement Knobs and Buttons

• Replacement personal mixer knobs, knob caps, and button key caps.

L-25 Cat-5e Cable

• Black Cat-5e unshielded cable (25ft/7.6m)
• Suitable for use with most Aviom products

PS-120 Power Supply

• 24VDC power supply
• Compatible with most DC-powered Aviom products
• PS-240 version is also available

AN-16/o v.4 Output Module

• 16 line-level analog outputs
• Selectable analog output level per channel pair

Mix320-A Personal Mixing System

• A 6-mixer system with a 16-channel analog interface, available with and without Iems

Mix320-D Personal Mixing System

• A Dante-based 6-mixer system that is available with and without 6 IEMs

Mix320-Y Personal Mixing System

• A Yamaha^® digital console card is used for the front end of this 6-mixer system. Also available with 6 IEMs.
